ASRock Intel Arc B580 Challenger 12GB OC GDDR6 PCIe 4.0 x8 1xHDMI/3xDP Video Card (B580 CL 12GO)

Intel Arc B580 Challenger 12GB OC
B580 CL 12GO

• CLOCK: GPU / MEMORY
  GPU Clock: 2740 MHz
  Memory Clock: 19 Gbps
• KEY SPECIFICATION
  Intel® Arc™ B580 Graphics
  12GB 192-bit GDDR6
  Intel® Xe2-HPG Architecture
  Intel® Xe Super Sampling 2 (Intel® XeSS 2)
  Intel® Xe Matrix Extensions (Intel® XMX)
  DirectX® 12 Ultimate
  1x 8-pin Power Connectors
  3x DisplayPort™ 2.1 / 1x HDMI™ 2.1a
• KEY FEATURES
  Dual Fan Design
  Stylish Metal Backplate
  Striped Axial Fan
  LED Indicator
  0dB Silent Cooling
  Super Alloy Graphics Card

Intel® Arc™ Graphics – Desktop Quick Start Guide

• Graphics Engine

  - Intel® Arc B580

• Bus Standard

  - PCI® Express4.0 x 8

• DirectX

  - 12 Ultimate

• OpenGL

  - 4.6

• Memory

  - GDDR6 12GB

• Engine Clock

  - 2740 MHz

• Intel® XMX Engines

  - 160

• Compute Units

  - 20

• Memory Clock

  - 19 Gbps

• Memory Interface

  - 192-bit

• Resolution

  - Digital Max Resolution: 7680 x 4320

• Interface

  - 1 x DisplayPort 2.1 (Primary, up to UHBR13.5)
  - 2 x DisplayPort 2.1 (Up to UHBR10)
  - 1 x HDMI 2.1a



• HDCP

  - Yes

• Multi-view

  - 4

• Recommended PSU

  - 650W

• Power Connector

  - 1 x 8-pin

• Accessories

  - 1 x Quick Installation Guide

• Dimensions

  - 249 x 132 x 41mm, 2-slot

• Net Weight

  - 720 g
