Intel 12th Gen Core i3-12100F 4-Core (4P) 3.3Hz LGA1700 58W Alder Lake No Graphics CPU Processeur (BX8071512100F)
UGS: BX8071512100F
$137.99
Options
Description du produit
Essentials
- Product Collection12th Generation Intel® Core™ i3 Processors
- Code NameProducts formerly Alder Lake
- Vertical SegmentDesktop
- Processor Numberi3-12100F
- StatusLaunched
- Launch DateQ1'22
- LithographyIntel 7
- Use ConditionsPC/Client/Tablet
- Recommended Customer Price$97.00 - $104.00
CPU Specifications
- Total Cores4
- # of Performance-cores4
- # of Efficient-cores0
- Total Threads8
- Max Turbo Frequency4.30 GHz
- Performance-core Max Turbo Frequency4.30 GHz
- Performance-core Base Frequency3.30 GHz
- Cache12 MB Intel® Smart Cache
- Total L2 Cache5 MB
- Processor Base Power58 W
- Maximum Turbo Power89 W
Supplemental Information
- Embedded Options AvailableNo
- DatasheetView now
Memory Specifications
- Max Memory Size (dependent on memory type)128 GB
- Memory TypesUp to DDR5 4800 MT/s
Up to DDR4 3200 MT/s - Max # of Memory Channels2
- Max Memory Bandwidth76.8 GB/s
Expansion Options
- Direct Media Interface (DMI) Revision4.0
- Max # of DMI Lanes8
- Scalability1S Only
- PCI Express Revision5.0 and 4.0
- PCI Express Configurations ‡Up to 1x16+4, 2x8+4
- Max # of PCI Express Lanes20
Package Specifications
- Sockets SupportedFCLGA1700, FCBGA1700
- Max CPU Configuration1
- Thermal Solution SpecificationPCG 2020C
- TJUNCTION100°C
- Package Size45.0 mm x 37.5 mm
Advanced Technologies
- Intel® Gaussian & Neural Accelerator3.0
- Intel® Thread DirectorNo
- Intel® Deep Learning Boost (Intel® DL Boost)Yes
- Intel® Optane™ Memory Supported ‡Yes
- Intel® Speed Shift TechnologyYes
- Intel® Turbo Boost Max Technology 3.0 ‡No
- Intel® Turbo Boost Technology ‡2.0
- Intel® Hyper-Threading Technology ‡Yes
- Intel® Virtualization Technology (VT-x) ‡Yes
- Intel® Virtualization Technology for Directed I/O (VT-d) ‡Yes
- Intel® VT-x with Extended Page Tables (EPT) ‡Yes
- Intel® 64 ‡Yes
- Instruction Set64-bit
- Instruction Set ExtensionsIntel® SSE4.1, Intel® SSE4.2, Intel® AVX2
- Idle StatesYes
- Enhanced Intel SpeedStep® TechnologyYes
- Thermal Monitoring TechnologiesYes
- Intel® Volume Management Device (VMD)Yes
Security & Reliability
- Intel® AES New InstructionsYes
- Secure KeyYes
- Intel® OS GuardYes
- Execute Disable Bit ‡Yes
- Intel® Boot GuardYes
- Mode-based Execute Control (MBEC)Yes
- Intel® Control-Flow Enforcement TechnologyYes
